IEI Technology AFL3-W19A-AL User Manual

AFL3-W19A-AL Panel PC
Page 50
4.3.2.2 Serial Port 1 Configuration
 Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.

Disabled
Disable the serial port

Enabled DEFAULT
Enable the serial port
 Change Settings [IO=3F8h; IRQ=4]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

IO=3F8h; IRQ=4 DEFAULT
Serial Port I/O port address is 3F8h and the
interrupt address is IRQ4

IO=3F8h;
IRQ=4, 10, 11
Serial Port I/O port address is 3F8h and the
interrupt address is IRQ4, 10, 11

IO=2F8h;
IRQ=4, 10, 11
Serial Port I/O port address is 2F8h and the
interrupt address is IRQ4, 10, 11

IO=3E8h;
IRQ=4, 10, 11
Serial Port I/O port address is 3E8h and the
interrupt address is IRQ4, 10, 11

IO=2E8h;
IRQ=4, 10, 11
Serial Port I/O port address is 2E8h and the
interrupt address is IRQ4, 10, 11
 Transfer Mode [RS232]
Use the Transfer Mode option to select the Serial Port 2 signaling mode.

RS422
Serial Port 6 signaling mode is RS-422

RS232 DEFAULT
Serial Port 6 signaling mode is RS-232

RS485
Serial Port 6 signaling mode is RS-485
