IEI Technology AFL3-W19A-AL User Manual

AFL3-W19A-AL Panel PC
Page 49
4.3.2 F81866 Super IO Configuration
Use the F81866 Super IO Configuration menu (BIOS Menu 4) to set or change the
configurations for the serial ports.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
F81866 Super IO Configuration
Super IO Chip F81866
> Serial Port 1 Configuration
> Serial Port 2 Configuration
Set Parameters of Serial
Port 1 (COMA)
---------------------
 : Select Screen
↑ ↓: Select Item
Enter Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 4: F81866 Super IO Configuration
4.3.2.1 Serial Port n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 5) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
Serial Port 1 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4
Change Settings [IO=3F8h; IRQ=4]
Enable or Disable Serial
Port (COM)
---------------------
 : Select Screen
↑ ↓: Select Item
Enter Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 5: Serial Port n Configuration
