AFL3-W19A-AL Panel PC

Page 92

6.2.1 SPI Flash Connector, EC (JSPI2)

PIN NO. DESCRIPTION

1 +3.3V

2 SPI_CS

3 SPI_SO_SW

4 SPI_CLK_SW

5 SPI_SI_SW

6 GND

Table 6-18: SPI Flash Connector, EC (JSPI2) Pinouts

6.2.2 Touch Panel Connector (TOUCH1)

PIN NO.

DESCRIPTION

8-Wire 4-Wire 5-Wire

1 Right Sense N/A N/A

2 Left Sense N/A N/A

3 Bottom Sense N/A N/A

4 TOP Sense N/A Sense(S)

5 Right Excite Right LR(X)

6 Left Excite Left LL(L)

7 Bottom Excite Bottom UR(H)

8 Top Excite Top UL(Y)

9 GND GND GND

Table 6-19: Touch Panel Connector (TOUCH1) Pinouts
