AFL3-W19A-AL Panel PC

Page 86

6.2.3 Inverter Connector (INV_CN1)

PIN NO. DESCRIPTION

1 +12V

2 +12V

3 Backlight on/off

4 Backlight Brightness Control

5 GND

6 GND

Table 6-7: Inverter Connector (INV_CN1) Pinouts

6.2.1 LAN1 Link LED Connector (LED_LAN1)

PIN NO. DESCRIPTION

1 +3.3V

2 LAN1_LED_LNK#_ACT

Table 6-8: LAN1 Link LED Connector (LED_LAN1) Pinouts

6.2.1 LAN2 Link LED Connector (LED_LAN2)

PIN NO. DESCRIPTION

1 +3.3V

2 LAN2_LED_LNK#_ACT

Table 6-9: LAN2 Link LED Connector (LED_LAN2) Pinouts
