6.2.3 M.2 A-key Slot (M2_AKEY1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 +V3.3A
3 USB+ 4 +V3.3A
5 USB- 6 NC
7 GND 8 Module Key
9 Module Key 10 Module Key
11 Module Key 12 Module Key
13 Module Key 14 Module Key
15 Module Key 16 NC
17 NC 18 GND
19 NC 20 NC
21 NC 22 NC
23 GND 24 GND
25 NC 26 NC
27 NC 28 NC
29 GND 30 GND
31 NC 32 NC
33 GND 34 NC
35 PCIE_TX+ 36 GND
37 PCIE_TX- 38 NC
39 GND 40 NC
41 PCIE_RX+ 42 NC
43 PCIE_RX- 44 NC
45 GND 46 NC
47 CLK_PCIE+ 48 NC
49 CLK_PCIE- 50 NC
51 GND 52 BUF_PLT_RST#
53 PCIE_CLKREQ# 54 Pull Up +V3.3A
55 PCIE_WAKE# 56 Pull Up +V3.3A
57 GND 58 NC
59 NC 60 NC
