IEI Technology AFL3-W19A-AL User Manual

AFL3-W19A-AL Panel PC
Page 56
4.3.6 RTC Wake Settings
The RTC Wake Settings menu (BIOS Menu 9) configures RTC wake event.
Aptio Setup Utility – Copyright (C) 2018 American Megatrends, Inc.
Advanced
Wake system with Fixed Time [Disabled] Enable or disable System
wake on alarm event. When
enabled, System will
wake on the
date::hr::min::sec
specified
----------------------
 : Select Screen
↑ ↓: Select Item
Enter Select
F1 General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save
ESC Exit
Version 2.18.1263. Copyright (C) 2018 American Megatrends, Inc.
BIOS Menu 9: RTC Wake Settings
 Wake system with Fixed Time [Disabled]
Use the Wake system with Fixed Time option to enable or disable the system wake on
alarm event.

Disabled D
EFAULT
The real time clock (RTC) cannot generate a wake
event

Enabled
If selected, the Wake up every day option appears
allowing you to enable to disable the system to wake
every day at the specified time. Besides, the
following options appear with values that can be
selected:
Wake up date
Wake up hour
Wake up minute
