Development Board Features
Development Kit User’s Manual 27
Description Comments
BIOS (SPI) Supports two compatible flash
device
Support for multi-vendor SPI
Support multi package (SOIC-8 & SOIC-16)
device
BIOS (Intel®
82802 Firmware
Hub Device)
Support for 8-Mb Intel® 82802
Firmware Hub Device using Port 80
card
No Intel® 82802 Firmware Hub Device
connector on motherboard
Support only through port 80 add-in card
(through the TPM header)
Soft Audio/Soft
Modem
Intel® High Definition Audio (Intel®
HD Audio) MDC Header
Support visa interposer
Use Mott Canyon 4 daughter card (support via
sideband cable)
HDA routed to docking connector
ATA/Storage 4 SATA Ports 2 Cable Connector and 1 Direct Connect
Connector, one eSATA connector
Both port 0 & port 1 have interlock switch.
USB 12 USB 2.0/1.1 Ports 6 ports to Back-panel I/O connector, 5 ports to
Front-panel I/O connector and 1 port to Docking
LPC One LPC slot Includes sideband headers
SMC/KBC Hitachi H8S/2117 micro-controller
Two PS/2 ports
One scan matrix keyboard connector
ACPI compliant
Clocks CK-505D system clock and DB800M Three 133/166/200/233/400 MHz CPU
differential clock pair
Twelve 100MhZ PCIe differential pair SRC clocks
Twelve 33 MHz PCI clocks
48-MHz USB clock, 14-MHz ref clock, 96-Mhz Dot
clock, Spread spectrum clocks
RTC Battery-backed real time clock
Thermal
Monitoring
Processor temperature sensor
Processor
Voltage
Regulator
Intel MVP6+ for processor core
Power Supply Desktop Mode
Mobile Mode
ATX Power Supply
Battery Pack (smart battery support)
Intel® Adaptive Mobile Power System (Intel®
AMPS) AC Brick
