Development Board Features
28 Development Kit User’s Manual
Description Comments
Port 80 display Through Add-in card. Four seven-segment
displays
Debug
Interfaces
Extended Debug Port (XDP) XDP connector (for processor run control)
Test points for manageability engine JTAG
LAI support
Intel® AMT
support
Intel® Active Management
Technology (Intel® AMT) is
supported on the CRBs with M0 M1,
and M-off management states
Controller Link to GMCH and to wireless LAN
Manageability engine power plane
Intel® Turbo
Memory
Support
Intel® Turbo Memory technology of
hardware cache is supported using
an Intel Turbo Memory Add-in card
Power
Management
ACPI Compliant C0, C1, C1E, C2, C2E, C3, C3E, C4E, slow C4
exit, Intel® Enhanced Deeper Sleep (with Level
5 read) and Deep Power Down Technology
processor power states for mobility processors
S0 (Power On), S3 (Suspend to RAM), S4
(Suspend to Disk), S5 (Soft Off) system power
states.
M0 (All Wells powered), M1 (Main Well down,
Only ME power on), M-off (ME powered off)
manageability power states
Form Factor ATX 2.2 like form factor 10 layer board – 12” x 10.2”
Miscellaneous Extended Battery Life (EBL) support
Intel® Display Power Saving
Technology (Intel® DPST) 4.0
support
SPWG3.5 complaint LVDS panel
support
Mobile Digital Office initiatives
TPM1.2 and support for Trusted
Platform Enabling
Intel AMT support
Lead free design
Note: Review the document provided with the Development Kit titled “Important Safety and
Regulatory Information”. This document contains safety warnings and cautions that
must be observed when using this development kit.
