Intellian GX60 User Manual

GX60 – Marine Satellite Communication System
106
4
Wi-Fi Access
Point
Conguration
- SSID : The SSID is the network name shared among all devices in a wireless network. The SSID
must be identical for all devices in the wireless network. It is case-sensitive and must not exceed 32
alphanumeric characters, which may be any keyboard character. Make sure this setting is the same
for all devices in your wireless network.
- Channel : Select an appropriate channel from the list provided to correspond with your network
settings. All devices in your wireless network must use the same channel in order to function correctly.
Try to avoid conicts with other wireless networks by choosing a channel where the upper and lower
three channels are not in use.
- Authentication Type : Module supports an authentication mode that the 802.11 device uses when it
authenticates and associates
with an access point or IBSS cell.
- Password : WiFi access password.
- Max Stations : Setting max stations.
- Disable SSID Broadcast : Select whether or not to broadcast the SSID in a wireless network. Select
Disable to display the network name continuously or select Enable to hide it from the list.
5
Network Service
Conguration
- Telnet Service : Enable or disable telnet login support.
- HTTPS Port : HTTPS port number.
- SSH Service: Enable or Disable the CLI access through the SSH protocol.
6
GX Local
Forward to PC
Port
To remotely access GX BDT from Intellian's Aptus PC Software, either HTTPS or SSH connection
needs to be forwarded. It is recommended to forward less preferred protocol. If "HTTPS" is often
used and Aptus PC software is also required, select "SSH to PC". If "SSH" is often used, select "Web
to PC".
7
Sys Log
Conguration
Set the system log conguration. Antenna sends log messages according to emergency level.
Enabling this function sends the message to your management server.
- Management Server : Sys log function enable/disable
- Server IP : Management server IP address
- UDP Port : Management port
- Message Type : Select message type (Intellian message level) to send to management server (Lower
number indicates higher emergency).
- Sys log Target Level : If you select this target level, the management server receives log message equal
to or less than this level.
8
Browser
Conguration
Setting refresh rate and refresh disable time.
- Refresh Rate : Set the browser refresh rate (Default 1 seconds. Range 1~99).
- Refresh Disable Time : Set the browser idle time-out (Default:9 minutes. Range 0~9). To use this
function, check the check box.
9
Dual Diversity
Conguration
This function is available when the antenna is connected to GX Mediator and GX BDT at the same
time.
- Activate: Select to use the GX Dual Antenna System. The GX BDT will communicate with GX
Mediator. For more information about the GX Dual Antenna System, refer to the “GX Mediator User
Guide” that came with the GX Mediator package.
- Inactivate: Select to use the GX Single Antenna System.
