56
Setup Mode
Enter the SETUP mode. Simply follow the instructions below.
Searching / Tracking mode
Setup mode
Exit setup mode
T R A C KI NG 0 6 2 . 6 E I5 _ F1 S I G : 2 01
A Z : 2 54 .3 ( 16 4 . 3 ) E L : 1 0 . 9 F n
1. While the antenna is in SEARCHING/TRACKING mode, touch MENU key to enter SETUP
mode.
*
indicates the key pad lock function is on (Refer to KEY LOCK menu to setup the key
pad lock function). When key pad lock function is activated touch MENU key or when “Fn” menu
is activated touch FUNCTION key then ENTER PASSWORD menu will be displayed.
SE T UP M O D E ?
Y E S N O
2. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode or
touch RIGHT arrow key to move cursor to NO and touch OK key to abort and return to the main
display.
EX I T SE T UP M O D E ?
Y E S N O
3. While the antenna is in SETUP mode, touch FUNCTION key as shortcut key to exit SETUP
mode.
