Contains the items required for securing the antenna unit and BDT to the vessel.
Installation Kit
BDT box
Description Q'ty Size Remarks
Below Deck Terminal (BDT) 1
43.1 cm x 44.1 cm x 4.4 cm
(17" x 17.3" x 1.7")
Below Deck Terminal
User Manual 1
RF Hazard Sticker 1 Radiation Safety Distance Label
Mounting Template 1
Wi-Fi Antenna 1 110mm
USB Flash Drive 1
Components box
Description Q'ty Size Remarks
BDT Bracket (Rack) 2 BDT-19inch Rack
BDT Bracket (Table) 2 BDT-Table
AC Power Cord (CEEE7/7) 1 1.5m BDT Power
AC Power Cord (USA) 1 1.5m BDT Power
4 Pin Power Connector 1 - CA 3 LD
PC Serial Cable 1 1.8m BDT to PC
USB Cable (A-A) 1 1.8m BDT to PC
Ethernet Cable (RJ45/LAN) 1 1.5m BDT to PC
N to F Adaptor 2 N(Male) to F(Female) Adaptor
Hex Bolt 5 M12 x 100L
Antenna-Deck 4 Sets :
Installation 1 Set : Spare
Flat Washer 5 M12
Spring Washer 5 M12
Hex Nut 10 M12
Hex Head Wrench Bolt 5 M6 x 40L
Radome (Spare Bolts)
Spring Washer and Flat Washer 5 M6
Self-Tapping Screw 5 M4 x 16 Table Mount Bracket
Flat Head Screw 10 M4 x 12L Rack Mount Bracket BDT
Sems Bolt 5 M3 x 12L Table Mount Bracket BDT
Radome Door Key 2 1 Door Key and 1 Spare Key
