17
Installing Antenna
Antenna Unit
The antenna unit includes an antenna pedestal inside a radome assembly unit. The pedestal consists of a satellite
antenna main dish with RF components mounted on a stabilized pedestal. The radome protects the antenna pedestal
assembly unit from the severe marine environment.
Antenna unit
