GX60 – Marine Satellite Communication System
46
PC to BDT Communication Setup
You can establish data communication between a PC and the BDT using one of the following methods.
TCP/IP Connection
Connection through Front Panel Management LAN Port
To connect the BDT to the PC through the Management LAN Port on the front BDT panel, the network should be
congured by setting up the PC IP before the connection. This method requires separate IP conguration on a PC.
1. Connect an Ethernet cable from a PC Ethernet port to the Management Port on the front of the BDT.
2. Go to Control Panel > Network and Sharing Center > Change Adapter Settings. Right-click on the Local Area
Connection and click Properties.
3. Select TCP/ IPv4, and click Properties.
4. Change the network settings on a PC. (Example)
- IP: 192.168.1.11 (Do not use 192.168.1.1~10, which are only for internal use.)
- Subnet Mask: 255.255.255.0
5. Use the following IP address to access Intellian Aptus or Aptus Web page.
- Default IP: 192.168.1.2
PC
Wi-Fi Connection
You can connect to the BDT via Wi-Fi for easy management and control whenever you are on the vessel.
1. Turn on the Wi-Fi power switch located on the rear of the BDT. After 30 seconds, conrm that a red light
appears on the switch.
2. Use the following IP address to access Intellian Aptus or Aptus Web page.
- Default IP: 192.168.1.2
