Intellian GX60 User Manual

43
Installing BDT
Selection of BDT Installation Site
The BDT should be installed below deck, in a location that is:
• Dry, cool, and ventilated.
• The front panel should be easy accessible to user.
BDT Dimensions
47.5cm ( 18.7")
45.5cm (17.9")
43.1cm (17")
20.0cm (7.9") 13.0cm (5.1")
48.5cm (19.1")
46.6cm (18.4")
3.2cm (1.3")
44.0cm (17.3")
4.4cm (1.7")
