Step 7.
Using 19mm wrench, remove the nuts (4EA) and washers (4EA) that mount the antenna to the pallet.
WARNING: When lifting the antenna using the lifting straps, make sure to remove the
securing nuts to separate antenna from the pallet.
Placing Antenna on Mast
The Intellian antenna comes with the lifting straps pre mounted from the factory. Before lifting, check the condition
of the lifting strap and that the shackle is tightened up. Ensure the protection is on to avoid damaging the radome.
Lift the antenna above the mast using the crane and maintain sufcient space(150mm) to perform cabling work.
