Technical Specification
Dimensions
Satellite antenna unit 90cm x 103cm (35.5” x 40.5”)
Antenna dish diameter 65cm (25.6”)
Below Deck Terminal 43.1cm x 44.1cm x 4.4cm (17” x 17.3” x 1.7”)
Weight
Satellite antenna unit 60kg (132lbs)
Below Deck Terminal 4kg (8.8lbs)
Antenna system
Tx Frequency 29.00~30GHz Ka-band
Tx Gain 43.75dBi @ 29.5GHz (with radome)
Rx Frequency 19.2~20.2GHz Ka-band
Rx Gain 40 dBi @ 19.7GHz (with radome)
Polarized Feed Circular, Tx:RHCP Rx:LHCP
G/T 17 dB/K (Typ.)
Azimuth Range Unlimited
Elevation Range -20° ~ +115°
Cross-level Range ±37°
Stabilization Accuracy 0.2° peak mis-pointing @ max ship motion condition
Max Ship’s motion ±25°roll, ±15° pitch, ±8°yaw@ 6 sec
BUC 5W Ka-band BUC
Power Consumption 100 ~ 240 V AC, 50 ~ 60Hz, 4A
Operating temperature range -25°C to 55°C
Storage temperature range -40°C to 80°C
Below Deck Terminal
Dimensions (WxDxH) 43.1cm x 44.1cm x 4.4cm / 17” x 17.3” x 1.7”
Weight 4kg / 8.8lbs
Display 2 line 40 character graphic VFD module
Ship’s Gyrocompass Interface NMEA 2000 / NMEA 0183
Modem Interface Integrated on the BDU
Remote Management Yes
Wi-Fi Operation Ye s
Management Port Yes (Ethernet/ USB/ Serial)
Power Requirement 100~240V AC, 50~60Hz, 1A
