GX60 – Marine Satellite Communication System
22
Antenna Dimensions
The method of installation and mounting of antenna may vary with vessel design, but the following procedures are
applicable in most situations and will result in a secure and effective installation. Conrm the height and diameter
of the antenna before installing it.
ø901.5mm (35.49”)
964.1mm (37.95”)
1029.1mm (40.51”)
60mm (2.36”)
