Antenna Settings
Manual Search
Search the desired satellite manually.
Antenna movement
Setup mode
Save
Manual search menu
Antenna menu
SE T UP M O D E ?
Y E S N O
1. Touch LEFT arrow key to move cursor to YES and touch OK key to enter SETUP mode.
+A N TEN N A + S A T EL L I T E
+ S Y S T EM
2. Touch OK key to enter ANTENNA menu.
+M AN U A L S E AR C H + D I A G NO S T I C
3. Touch OK key to enter MANUAL SEARCH menu.
S T E P SI Z E AZ I M UT H E L E V AT IO N A G C
# 0 0 . 2 #
2 3 1 . 7 4 8 . 3 3 0 1 F n
4. Current IF tracking signal level (AGC)/(SIG/dB scale) is displayed to assist you in manually
peaking AZIMUTH (0°-360°) and ELEVATION (0°-90°) angle for best signal level.
Touch NUMBER key to change the STEP SIZE (Range: 0.1~99.9). Touch LEFT and RIGHT arrow
keys to increase or decrease the azimuth angles. Touch UP and DOWN arrow keys to increase
or decrease the elevation angles.
Touch FUNCTION key to save current settings or abort and return to the main display.
S A V E C U R RE N T S A T IN F O ?
Y E S N O
5. If the current settings are able to locate the satellite, touch FUNCTION key to save “current
satellite information”. This will help to reduce the satellite acquisition time after restarting the
system. Touch LEFT arrow key to move cursor to YES and touch the OK key to save the settings.
NOTE: If the gyrocompass type is not NMEA or the gyrocompass is not connected to the
BDT, the information cannot be saved.
