84
7. GUI
This view shows a graphical representation of the current antenna position which
allows you to easily identify whether or not the antenna is aligned properly to the target
satellite or is in a block zone. In addition, this view shows the current
satellite that the antenna is pointed towards and the satellites that are located at a
180° arc on the horizon, according to the current position.
NOTE: Based on the satellite EIRP footprint and the size of the antenna, you may not be
able to track all the satellites visible in 180° arc.
