Intermec EasyCoder 501 E – Installation & Operation Ed. 1 121
Chapter 13 Adjustments
❑ If the cursor is not situated correctly, the LSS must be adjusted.
• The LSS emitter can be set to a value between 0 and 127. Try to fi nd
the correct level by means of the following keys:
<F2> decreases the level 1 step.
<F3> increases the level 1 step.
<F4> decreases the level 10 steps.
<F5> increases the level 10 steps.
Keep trying until you fi nd the right level.
• When the adjustment looks right, press <Feed>. Th is wi ll pro duc e
a TESTFEED, that is, it will allow the printer feed out one label,
ticket, tag, or piece of strip in order to adjust itself and to allow
you to check that the media feed works correctly. At least two
TESTFEEDs should be produced before you go on.
• If you cannot make the LSS work correctly by following the
instructions above, you may–as a last resort–need to adjust the
potentiometer on the CPU board, see Appendix 3. Read the
instructions carefully before starting, since you will be working in
a part of the printer with live high-voltage components!
• Try different combinations of potentiometer settings and LSS
levels until the cursor is positioned correctly.
• When you are satisfi ed that the LSS is set up correctly, press
<Enter>. That will set the LSS and let you proceed to next part
of the Detection setup, see Chapter 8.
Label Stop
Sensor, cont.
