Intermec EasyCoder 501 E – Installation & Operation Ed. 132
Chapter 5 Media Load
Cut-Off, cont.
3
Turn the printhead lift lever to “Load” posi-
tion.
4
5
6a
Remove any empty core from the media
supply hub.
Fit a new roll of media on the supply hub and
push the roll inwards as far as it will go.
38-40 mm
(1.5 in)
Turn the label slack absorber clockwise so it
snap-locks in open position.
To Next Page
