Intermec EasyCoder 501 E – Installation & Operation Ed. 134
Chapter 5 Media Load
Cut-Off, cont.
Route the media through the cutter between the
two guide plates.
11
12
13
Close the cutter while pulling at the end of the
media. Close the right-hand door.
10
2.
1.
Release the slack absorber (1). Adjust the
green edge guide so the media is guided with a
minimum of play (2).
Turn the printhead lift lever to “Print” posi-
tion.
