Intermec EasyCoder PF4i User Manual

Chapter 9 — Maintenance
EasyCoder PF4i User’s Guide (IPL Version) 89
Cleaning the Media Guides
The label stop sensor, which controls the media feed, is partially
enclosed by two plastic guides. Light passes through slots
between the upper and lower part of the sensor. If these areas are
not clean, stuck labels or other objects may block the light beam
and the label stop sensor will not function.
If the printer starts to feed out labels in an unexpected way,
remove the guides as described below and check for anything
blocking the beam of light, such as dust, stuck labels, or adhesive
residue. If necessary, clean the guides using a cleaning card or a
soft cloth soaked with isopropyl alcohol. Do not use any other
type of chemicals.
To clean the Media Guides
1 Pull the upper guide straight out. (Upper part of print unit
omitted for better view.)
Isopropyl alcohol [(CH-3)2CHOH; CAS 67-63-0] is a highly
flammable, moderately toxic, and mildly irritating substance.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
