Intermec Standard Protocol
The Intermec Printer Standard Protocol is a half-duplex protocol.
All data transmissions to the printer consist of status inquiry
(ENQ), status dump (VT), or message blocks. Each message
block starts with the Start of Text (STX) character and ends with
the End of Text (ETX) character. Each message block must be
255 characters or less, including the STX and ETX characters.
The printer responds to each status inquiry or message block
with the printer status. The host should check the printer status
before downloading a message block to the printer. ENQ causes
the printer to transmit its highest priority status, while VT
instructs the printer to transmit all status that applies in the order
of their priority. The possible printer status, in descending
priority, is:
Test/Service
Testprint
This part of the Setup Mode allows you to print various types of
test labels. Go to the desired option and press Enter. The printer
will start printing the test label or labels. Press the Feed/Pause
button to hold the printing temporarily. To resume printing,
press the Feed/Pause button again. The following options are
available:
Condition Character
Buffer already full GS
Printhead raised US
Ribbon fault US
No label stock EM
Buffer now full DC3
Printhead hot SI
Label at strip pin FS
Label skipping DC1
Ready DC1
Printing DC1

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
