Intermec EasyCoder PF4i User Manual

Chapter 5 — Setting Up the Printer
50 EasyCoder PF4i User’s Guide (IPL Version)
Description
Setup defines the printer’s serial communication, test and service
operations, and specifies which types of media and ribbon are
loaded in the printer. If the printer’s default setup does not meet
your requirements, follow the instructions in “Setup Mode” on
page 61 to change the setup.
Default Setup
This list does not include options.
Ser-Com
Baud rate 9600 bps
Data bits 8 bits
Parity None
Stop bits 1 bit
Protocol XON/XOFF
Test/Ser vice
Testprint Not Applicable
Data dump No
Memory reset Not Applicable
Media
Media type Gap
Paper type DT
Label length dots 1200 dots
Sensitivity 420
Darkness 0%
Label rest point 0 dots
Form adj dots X 0 dots
Form adj dots Y 0 dots
Configuration
Power up emulation
None
Print speed 4 in/sec
Cutter Not installed (optional)
Label taken sensor Not installed (optional)

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
