Display
The display window contains an LCD (Liquid Crystal Display)
with background illumination and two lines of text, each with 16
characters. It shows a message when certain errors occur and
guides the operator through upgrading, startup, and setup. The
following errors are reported:
Keyboard
The keyboard is of the membrane-switch type and has seven keys,
plus one large “Feed/Pause” button. Some keys have hard-coded
functions in Startup and Setup modes.
Error Messages and Conditions
Message Displayed Error Condition
PAUSE Empty/Paused
PAPER OUT Out of media
RIBBON OUT Out of ribbon
PRINT HEAD UP/PRESS
FEED
Printhead lifted
OPEN&SHUT CUTTER Cutter error
RIBBON FITTED Ribbon fitted
PAPER FAULT Paper fault
Feed/Pause button Feeds a page or pauses a print job. Also can
repeat last printed label.
Enter Setup Mode. For more information, see
Chapter 6, “Setup Mode” on page 61.
Display error message and communication
channel information.
Scroll between types of information after
pressing the Information key. Possible error
messages and information on active
communications channels are shown in a loop.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
