Chapter 9 — Maintenance
96 EasyCoder PF4i User’s Guide (IPL Version)
Media Jams
Should a media jam occur in the print mechanism, proceed this
way to clear it.
To clear a media jam
1 Always switch off the power before starting to clear the
jammed media.
2 Raise the printhead and pull out the media.
3 If the media has been wound up on or has stuck to the platen
roller, carefully remove it by hand without using any sharp
tools that can damage the delicate platen roller or printhead.
Avoid rotating the platen roller.
4 Cut off any damaged or wrinkled part.
5 Check if there is any adhesive somewhere in the print
mechanism. If there is, remove it using a cleaning card or a
cotton swab soaked in isopropyl alcohol.
6 Reload the media as described in Chapter 3.
7 Switch on the power.
8 Readjust the media feed by raising and closing the printhead
and then pressing the Feed/Pause key.
If you must pull away the media by force causing the
platen roller to rotate, it is very important that the power
has been off for a minute or more. If not, the electronics
can be damaged beyond repair.
Isopropyl alcohol [(CH-3)2CHOH; CAS 67-63-0] is a
highly flammable, moderately toxic, and mildly irritating
substance.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
