Intermec EasyCoder PF4i User Manual

Chapter 2 — Installation
6 EasyCoder PF4i User’s Guide (IPL Version)
Front View
At the front of the printer are the display window, the indicator
lamps, and the keyboard. These features allow the operator to
control and set up the printer manually. Printed labels, tickets, or
tags are presented at the front of the print mechanism. Refer to
Chapter 7, “Options” on page 67, for information on possible
optional devices that can be fitted on the printer’s front.
Front View of Printer
Indicator lamps
Display window
Keyboard
Feed/Pause button
Print mechanism

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
