Chapter 3 — Media Load
32 EasyCoder PF4i User’s Guide (IPL Version)
Peel-Off (Self-Strip)
The EasyCoder PF4i printer can print on labels, tickets, tags, and
continuous stock in various forms.
This section describes the case when self-adhesive labels are
separated from the liner immediately after printing, which
requires an optional internal liner takeup unit. For more
information, see “Integral Liner Takeup Kit” on page 70. This is
also known as “Self-strip” operation.
Peel-off can only be used for self-adhesive labels with liner.
An optional label-taken sensor can hold the printing of the next
label in a batch until the present label has been removed. For
more information, see “Label Taken Sensor” on page 71.
To load media for peel-off operation:
1 Open the side door.
Note: Peel-off operation sets high demands on the media for
proper label stiffness, release characteristics of the adhesive and
liner, resistance against electrostatic charge, and so on. If these
specific requirements are not met, the labels will not dispense
properly. Consult your media supplier or test the media to make
sure it is suitable for your application.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
