Intermec EasyCoder PF4i User Manual

Chapter 2 — Installation
8 EasyCoder PF4i User’s Guide (IPL Version)
Media Compartment
The media compartment is covered by a long side door that
completely encloses the print mechanism and media
compartment, or a short side door that only covers the print
mechanism and gives easy access to the media stock. The door is
held by a magnetic lock. It can be opened 180° to provide full
access to the media compartment.
Media Compartment
The media can be supplied from a rotating hub or from an
external supply of fan-folded media behind the printer. There is
also an optional rotating media supply hub. For more
information, see Chapter 7, “Options” on page 67.
Thermal transfer mechanism
Print mechanism
Long side door
Media supply
roll post with
edge guide
Optional integral
liner takeup with
guide shaft

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
