Intermec EasyCoder PF4i User Manual

Chapter 7 — Options
68 EasyCoder PF4i User’s Guide (IPL Version)
Overview
The EasyCoder PF4i printer provides a high degree of flexibility
because it has a modular design. By adding options to the basic
printer, the EasyCoder PF4i printer can be adapted for a variety
of applications. Some options should be installed by an
authorized service technician or are only available as factory-
installed options.
DTP Model
In the dedicated direct thermal printing (DTP) model, the
thermal transfer ribbon mechanism is omitted. The printer’s
default setup changes to direct thermal printing and setup
parameters for thermal transfer printing are not displayed.
Printhead spring
Label taken sensor
Paper cutter
Cutter tray
Short side door
Long side door
Long side door
with 8-in. Megatop
Transfer ribbon
mechanism
Covers
Interface board
(various types)
Media supply
roll post
3-inch adapter
1.5inch rotating
supply hub
Quick-Load
guides (included)
Liner takeup
and guide shaft
Thick media
printhead

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
