Chapter 2 — Installation
EasyCoder PF4i User’s Guide (IPL Version) 7
Rear View
The rear plate contains the On/Off switch, the AC power cord
socket, and various interface connectors and slots.
Rear View of Printer
Provision for EasyLAN
ethernet connection
(option)
Memory card slot
(firmware upgrading only)
Provivion for IEEE 1284
parallel interface board
On/Off switch
AC power cord socket
RS-232 serial interface
Machine label
