Intermec EasyCoder PF4i User Manual

Chapter 5 — Setting Up the Printer
EasyCoder PF4i User’s Guide (IPL Version) 59
To return to factory default setup using the keyboard
1 Lift the printhead.
2 Switch on the power to the printer and press the <i> key and
wait until the printer beeps.
3 Swiftly press the following keys.
4 The following message will be displayed:
5 Within 10 seconds, press Enter to reset the printer to factory
default. The parameters will be reset and the printer will
continue the normal startup.
If you press or wait until the 10 seconds time-out
has passed, the normal startup process will continue without
any reset being performed.
Note: Resetting to the factory default will reset all files used to
store settings, but it does not affect settings that were already
loaded before the files were removed. This means that, for
example, EasyLAN Wireless settings (SSID, keys, etc.) retain
their values until the next reboot. To reload all settings, reset the
printer to the factory defaults and then reboot it.

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
