Intermec EasyCoder PF4i User Manual

Chapter 8 — Troubleshooting
EasyCoder PF4i User’s Guide (IPL Version) 75
Note 1: This is only applicable for printers equipped with an
EasyLAN interface.
Note 2: A printer that is equipped with an EasyLAN interface,
but is not connected to a network, will have a blinking RTW. To
avoid this, set “IP SELECTION” to “MANUAL” and “IP
ADDRESS” to “0.0.0.0”. This will indicate that the lack of
network connection is not an error.
Note 3: No trap can be sent when this error/event occurs.
Note 4: This error indicates that the printer has not received an
IP address. It is only applicable for printers with IP
SELECTION set to DHCP and/or BOOTP.
Pause mode entered Blink PAUSED
Setup mode entered Blink Including
interactive
setup.
IP link error Blink See notes 1, 2,
and 3 below.
IP configuration error Blink See notes 1, 3,
and 4 below.
Printhead not found Off NO
PRINTHEAD
Rebooted Off
Initializing Off Appears at
startup until
printer is
operational.
Printer crash Off See notes 3
and 5 below.
Printer turned off Off
Maintenance Off Appears when
upgrading.
Power supply over
temperature
Off PSU OVER
TEMP
Printhead hot Off PRINTHEAD
HOT
See note 6
below.
Displayed Error Messages and LED Indicators (continued)
Error/Event
RTW
Status
Displayed Error
Message
Comment

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
