Intermec EasyCoder PF4i User Manual

Chapter 8 — Troubleshooting
78 EasyCoder PF4i User’s Guide (IPL Version)
Printout Missing Along Inner Edge
Possible Cause Remedy Reference
Bad media alignment Adjust media alignment Chapter 3
Using small core with supply
post in upper position.
Move post to lower
position
Chapter 2
X-start parameter value too low Increase value Chapter 5
Transfer Ribbon Breaks
Possible Cause Remedy Reference
Ribbon not fitted correctly Reload ribbon correctly Chapter 4
Wrong media grade Change parameter, then
clean printhead
Chapter 5,
Chapter 9
Bad energy control Adjust Call Service
Transfer Ribbon Wrinkles
Possible Cause Remedy Reference
Faulty ribbon break shaft adjustment Adjust shaft. Chapter 10
Incorrect edge guide adjustment Adjust edge guide Chapter 3
Printhead pressure too strong Adjust pressure Chapter 10
No Thermal Transfer Printout
Possible Cause Remedy Reference
Ink-coated side of ribbon is not facing
media
Reload ribbon Chapter 4
Media Feed Not Working Properly
Possible Cause Remedy Reference
Changed media characteristics Press the Print button Chapter 3
Wrong label rest dots parameter Check/change Chapter 5
Wrong Media Type parameter Check/change Chapter 5
Wrong LSS position Check/change Chapter 10

Intermec EasyCoder PF4i Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Power consumption (standby)	15 W
Power consumption (printing)	300 W
Media thickness	3/7.5 mm
Maximum label width	104 mm
Maximum label length	0.4 m
Maximum roll diameter	152.4 /213 mm
Maximum internal memory	1 GB
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Product color	Blue, Silver
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	405 mm
Width	244 mm
Height	178 mm
Weight	8000 g
