3 Product Specifications
The following sections outline the specifications for each scanner.
3.1 Mid-Power Scanner
Table 3-1 Mid-Power Scanner Specifications
Optical Specifications
Wavelength (nm)
1030 – 1080
Clear Aperture (mm)
12
Available Fiber Adapters
HLC-8 or 35mm Collimator Input
Collimator Length – HLC-8 Only (mm)
50
Low Power Lens Specifications
Maximum Multimode Power (kW)
.200
Maximum Single Mode Power (kW)
.200
Focal Length Options (mm)
100
163
254
330
420
Field Size ([X]mm x [Y]mm)
60 x 60
110 x 110
170 x 170
204 x 204
300 x 300
Nominal Working Distance (mm) +/-5%
102
186
285
390
493
Fused Silica (Multimode) Lens Specifications*
Maximum Multimode Power (kW)
2
Focal Length Options (mm)
163
254
Field Size ([X]mm x [Y]mm)
80 x 80
160 x 160
Nominal Working Distance (mm) +/-5%
136
244
Fused Silica Lens Specifications**
Maximum Multimode Power (kW)
2
Maximum Single Mode Power (kW)
.5
Focal Length Options (mm)
100
163
254
420
Field Size ([X]mm x [Y]mm)
50 x 50
102 x 102
175 x 175
280 x 280
Nominal Working Distance (mm) +/-5%
125
204
304
512
Dynamic Performance
Tracking Delay (µs)
100
Repeatability [rms] (µrad)
< 5
Available Control Schemes
IPG Scan Controller or XY2-100 Interface
Approximate Weight – Head Only (kg)
4-6 (configuration dependent)
*Not Optimized for single mode lasers.
** Not available in scanner configuration. Scanner must be ordered without lens and lens must be
ordered separately.
