IPG Photonics Scanner Series - High-Power Scanner

18
3.2 2D High-Power Scanner
Table 3-2 High Power Scanner Specifications
Optical Specifications
Wavelength (nm)
1030 – 1080
Clear Aperture (mm)
33
Available Fiber Adapters
HLC-8, HLC-8 with Rotary, LCA, or HLC-16
Maximum CW Power Handling (kW)
12
Maximum Single Mode Power Handling (kW)
2
Collimator Specifications
Collimator Focal Length Options (mm)
100
120
140
160
Maximum Multimode Power (kW)
12
12
12
2
Maximum Single Mode Power (kW)
2
2
2
2
Focus Lens Specifications
Focal Length Options (mm)
250
400
500
Nominal Working Distance (mm) +/-5%
261
415
526
Field Size ([X]mm x [Y]mm)
110 x 110
200 x 200
250 x 250
Angle of Incidence at X Edge of FOV
±4.13˚
±8.25˚
±9.18˚
Angle of Incidence at Y Edge of FOV
±6.42˚
±9.79˚
±10.34˚
Beam Divergence Full Angle
7.4˚
4.58˚
±2.52˚
Dynamic Performance
Tracking Delay (µs)
500
Repeatability [rms] (µrad)
< 5
Available Control Schemes
IPG Scan Controller
Approximate Weight –Head Only (kg)
11.3-14.0 (configuration dependent)
