9.4 Spare Parts List
The following sections outline specific product part numbers that the user may want to keep on-hand
for maintenance or repairs.
This is not an exhaustive list of system components and the user should review their application for a
complete list of spare part/maintenance items. Additionally, on-hand quantity should be considered by
the customer and tailored to the specific application.
IMPORTANT
Lead-Times: Please inquire with IPG Service for approximate lead-time on the
following items.
9.4.1 2D High-Power Scanner
Table 9-1 outlines maintenance and spare parts for the 2D High-Power Scanner.
Table 9-1 2D High Power Scanner Maintenance and Spare Parts
Description
Part Number
Recommended On Hand Quantity
Window Assembly (For
CDSH0007… Series Scanners)
CDSBOM000008XXXU
1-2 (dependent on number of systems)
Window Assembly with Dirty
Window Sensor (For
CDSH0009… and CDSH0010…
Series Scanners)
CDSBOM000093LDXU
1-2 (dependent on number of systems)
Window O-Ring (For
CDSH0007… Series Scanners)
CMMIXXX1002305PX
1-2 per head
Window O-Ring (For
CDSH0009… and CDSH0010…
Series Scanners)
CMORORI0000034PX
1-2 per head
Window (Coverslide)
COPWXXXXXXXX032U
4-5 per head
Protective Window Cover
P45-017834
1 per head
3m Control Cable (Standard)
CEU00001089XXXXU
1 of the proper length
3m Control Cable (FLEX)
CEKBASY0000093PX
5m Control Cable (Standard)
CEU00001865XXXXU
5m Control Cable (FLEX)
CEKBASY0000094PX
10m Control Cable (FLEX)
CEKBASY0000045PX
Motion Interface Board
CMUS1001478XXXXU
1 (choose the board specific to your
application)
Extended I/O Interface
CDSBEM000017XXXU
24V Interface
CDSBEM000001XXXU
