4.2.2 Mass Properties
The following mass properties were taken from the center point of the mounting holes. The positive Z
axis goes from the mounting holes towards the IPG logo. The positive X axis goes from the mounting
holes up towards the laser fiber inlet.
For mass properties specific to the users application, please provide product configuration details along
with any accessories to an IPG Product Specialist for more detailed results.
Table 4-1 2D High-Power Scanner Mass Properties without Accessories
2D High-Power Scanner Mass Properties without Accessories
Mass (kg)
11.5
Center of Mass (mm)
X = 1.37
Y = -27.32
Z = 78.55
Moments of Inertia (kg*mm
2
)
Ixx = 145963.88
Ixy = -23828.98
Ixz = -10983.61
Iyx = -23828.98
Iyy = 161693.82
Iyz = -14755.43
Izx = -10983.61
Izy = -14755.43
Izz = 134561.74
For mass properties specific to the user’s application, please provide product configuration details along
with any accessories to an IPG Product Specialist for more detailed results.
