IPG Photonics Scanner Series - High Power Scanner

19
3.3 3D High Power Scanner
Table 3-3 3D High Power Scanner Specifications
Optical Specifications
Wavelength (nm)
1030 – 1080
Available Fiber Adapters
HLC-8, HLC-8 with Rotary, LCA, or HLC-16
Maximum Power Handling (kW)
10
Magnification
3.6x
Field of View Size ([X]mm x [Y]mm x [Z]mm)
300 x 300 x 100
Nominal Working Distance (mm)
470
Dynamic Performance
Tracking Delay (µs)
1000
Repeatability [rms] (µrad)
< 5
Available Control Schemes
IPG Scan Controller
Approximate Weight – Head Only (kg)
15.8-18.2 (configuration dependent)
