4.3 IPG Scan Controller
4.3.1 Fans and Cooling
Figure 4-6 outlines the fan location on the Scan Controller.
Figure 4-6 Scan Controller Fans
CAUTION
THE SURFACE OF THE CONTROLLER CAN BE HOT, PARTICULARLY IN HIGH AMBIENT
TEMPERATURES! LEAVE sufficient CLEARANCE for AIR INPUT (FANS) and AIR EXITS.
IPG recommends a minimum of 12mm under normal conditions. High ambient
temperature or continuous operation may require additional clearance.
