JLG X20JPLUS - Emergency Descent in the Case Where the Stabilisers Are Accidentally Retracted

USINGTHEMACHINE
117
MUX20JP021602
BoomLiftModels X20JPLUS
11.5.3.Emergencydescentinthecasewherethestabilisersareaccidentallyre‐
tracted
Whileitisrecommendedtofollowtheinstructionsprovidedintheparagraphon
stabilisingthemachine,forvariousreasonsoneofthestabilisersmaylosecontact
withtheground,thuschangingtheangleofthemachine orcausingafootplate
toli
ftfromtheground.Ifthisoccurswhenthemachineisataheight,movements
arestoppedanddisabledimmediately.Torestoreoperationoftheplatform(close
theaerialpartandthenstabilisethemachineagain)theelectricalemergencyde‐
scentfunctioncanbe used,whichinvolvesonlythere
turnoftheaerialpart.Ifthis
isnotpossibleduetothepresenceofobjectsthatinterferewiththeoperation,per‐
sonnelonthegroundcanallowtheoperatorinthebaskettoclosethemachine.
Theoperatorsonthegroundcanbypassthemachineʹssafetydevicesand allow
theoper
atorinthebaskettoclosethemachineorallowthemanualoperationsas
describedinthepreviouspa ragraphs,inordertobringtheoperatorbacktothe
ground.
Proceedasfollows:
Readtheinstructionspro vided below beforeperformingtheop era‐
tionasitispotentiallydangerousfortheoperatorinthebasket.
1 Opentheelectricalcom‐
ponentscompar
tment.
Fig.115 Electricbox
