9.3.3. Emergencycontrolposition
Thereisacontrolpositionwhichwillbeidentifiedasthe emergencycontrolpo‐
sition.Thisislocatedonthegroundpartofthemachine,nexttothedistributor
fortheaerialpart.Toenableit
,pressthespecialselectorpositionedonthebase
oftheturretuntilthegreenwarninglightcomeson.Thelightindicatesthatthe
movementsoftheaerialpartareenabled.
From this position, the movements of the machine can be controlled directly
usingtheleversontheva
rioushydraulicdistributors,aerialpartandprop ortio‐
nal.
Fromthiscontrolposition,theoperatorISNOTenabledtocontroltheaerial
partofthemachine,butonlythetracks,stabilisersandtrackextensionfun‐
ction.
Whenco ntrollingthemachinefromthegroundposition,keepadi‐
stanceofatleast1mfro
mthetracks.
When controlling the machine from the ground position, always
makesurethatthecomponentthatisbeingmovediscompletelyvi‐
sibleandconstantlycheckitstrajectory.
Fig.58 SelectorPetrol/Dieselversion Fig.59 SelectorLithiumversion
