JLG X20JPLUS - JIB Position Micro Switch; Ropes Integrity Micro Switch

SAFETYDEVICE
45
MUX20JP021602
BoomLiftModels X20JPLUS
8.6. JIBPOSITIONMICRO SWITCH
Thepositionofthejibarmisdetectedbyamicroswitchthatissecuredtothejib
armitself.Themicroswitchmustbereleasedwhenthejibarmisclosed.
8.7. ROPESINTEGRITYMICROSWITCH
Theintegrityoftheropessystemthatmovesthetelescopicarmisve
rifiedbya
microswitchthatdetectsthepositionoftheropepullbalancingsystem.
Checkthecorrectoperationofthemicroswitcheseveryday.
Fig.17 JIBmicroswitch
ChecktheconditionandcorrectoperationoftheJIBmicroswitcheveryday.
