JLG X20JPLUS - Battery Cut-Out Switch; Distributor Pressure Relief Valves

42
BoomLiftModels X20JPLUS
SAFETYDEVICE
MUX20JP021602
8.1. BATTERYCUT‐OUTSWITCH
Thisdeviceisusedtoisolatethemachineʹselectricalcircuit.Itiswellvisibleand
easilyaccessedwithoutusingtools.Itonlyneedstobeactivatedforprolonged
machinedowntimeormaintenanceoperations.Turningthekeyclockwisecloses
themachineʹselectricalcircuit,whileturningitanticlockwiseisolatesthemachi‐
neʹsele
ctricalcircuitandthekeycanberemoved.
8.2. DISTRIBUTORPRESSURERELIEFVALVES
Fig.7 BatterycutoutswitchthermalEn‐
gineversion
Fig.8 BatterycutoutswitchLithiumver‐
sion
Beforedisconnectingthebatterybymeansofthisdevice,makesure
thattheenginekeyisinposition“off”an
dtheremotecontroland
electronicboardareoff.
Fig.9 Aerialpartpressurereliefvalve Fig.10 Groundpartpressurereliefvalve1
