JLG X20JPLUS - Recharging the Battery; Battery Charging Petrol;Diesel Engine

132
BoomLiftModels X20JPLUS
USINGTHEMACHINE
MUX20JP021602
11.7.RECHARGINGTHEBATTERY
11.7.1.BatterychargingPetrol/Dieselengine
Themachineisequippedwithachargingsystemofthebattery.UsingthePetrol/
Dieselenginetoaregimeofrevolutionsexceeding2200rpmthebatteryisrechar‐
gedbythecurrentgenerator.Thereisalsothepossibilityofrechargingthebat‐
terybythepowersupply.
Todothi
s,proceedasfollows:
•Checkthatthebatterycut‐outisconnected.
•Powerthemachinebyanelectriccableconnectingittothesocketonthechas‐
sisneartheelectricmotorandactivatethemainsupplyswitchinthecontrolca‐
binetofthemotor.
•Inthisconditiontheb
atterychargermountedonthemachinerechargesthe
battery.
bothconnectorsmustbeclosedwiththerespectivesealingplugstoprevent
moisturefromentering.
Fig.144 Mainsupplysocket Fig.145 Mainsupplyswitch
Rechargingbatterymustbecarriedoutinanventilatedareaaway
fromopenflamesorsourcesofignition.Inordernottocauseda
mage
tothebatteryisappropriatetorechargethesameonlywhentheam‐
bienttemperatureisbetween0and40°C
