7.5. TERMINOLOGY
Tomakethecontentsofthismanualeasiertounderstand,thediagramprovided
belowillustratesthetermsusedtoidentifythepartsofthemachine.
LEGENDA
Fig.6 Terminologymachinecomponents
1Trackedundercarriage
2 Revolvingturret
3Turntable+rotationmotor
4Emergencycontrols
5 Base+electricalcomponentcompartment+oi ltank
6Doublegearpump
7 Petrol/dieselengine/Batterypack+in
verter+batterycharger(LITHIUM
MOTOR)
8 Stabilizer
