24
BoomLiftModels X20JPLUS
TECHNICALINFORMATIONS
MUX20JP021602
9 Stabilizercylinder
10 Secondarmtierod
11 Secondarm
12 Second‐thirdarmcylinder
13 Second‐thirdarmtransmissi on
14 Second‐thirdarmconnectingrod
15 Basketlevellingcylinderonthetransmission
16 Thirdarm
17 Stabilizerplate
18 JIBtierod
19 Firstextensionarm
20 Jibcylinder
21 RightandleftJIBarm
22 Secondextensionarm
23 Remotecontrol
24 Basketorcage
25 Basketsupport
26 Rotaryactuatorforbasketrotation
27 Basket
leve
llingcylinderonthebasket
28 JIBtransmission
29 First‐secondarmtransmission
30 First‐secondarmcylinder
31 Firstarm
32
33 Electricmotor
34 Doublegearpump
35 Emergencyhandpump
