TRAVELLINGONSLOPES
11.4.7.JIBboommovementfortravel
Totakeonslopesfrom10°to15°inalongitudinaldirectionduringtravel,theJIB
armcanberaised.
The maximum slope for travel is
showninthemachinespecificationsat
the beginning of this manualʺTechni‐
caldata(p. 19)ʺ.Whentravellingonin‐
clinedsurf
aces,lowerthestabiliserson
thedownwardsideforfurthersafetyin
theeventofsuddenchangesinslope.
The machine is equipped with an automatic system of inclination
sensingduringtranslation,thepossibletranslation speedsareadju‐
stedaccordingtotheweightinbasket,undercarriageclosedorope‐
ned,positionofJIBan
dinclinationoftheground.Incaseofapproach
todangerousinclinationsformachineʹsstability,bothlateralandlongitudi‐
nal, a beeper is activated and afterwards the translation is forbidden. The
onlyallowedoperationtoexitthisconditionisactivatetheconsenttomove‐
mentpressingbutton8onremotecontrolandbr
ingthemachineinsafety
conditionreducingtheinclination,itisabsolutelyforbiddentoincreasethe
inclination of the machine as it could cause overturning with consequent
dangerforoperatororpeoplenearbythemachine.
Thesafetysystemsintroducedtolimittherisksofthemanoeuvreareavalid
helptoth
eoperatorbutunfortunately cannoteliminatedangerscausedby
improperorregardlessuseofthemachi ne.Itisoperatorʹsresponsibilityto
runthemachinesafely,checkingthegroundconditions,evaluatingtheob‐
staclesanddangersintheworkingareaandfollowingtherulesofthisma‐
nualandindicationsondecalsanddi
splayofthemachine.
