•Itismandatorytomakenewtraversingmovementspositioningthecarriage
atmaximumwidth,everytimetheplaceyouaretraversingallowsit.Thiswill
makesteeringeasierandincreasemachinestability.
•Thesecondtravelspeedcanonlybeusedduringstraight,flattraversingon
solidground.
OPERATIONALPHASESFORTRAVEL
a Be
foretravelling,proceedasfollows:
–Checkthatallinstructionspreviouslygiveninthischapt erhavebeencom‐
pliedwith;
–Makesurethatthegroundiscompactandcansupporttheweightofthe
machine;
–Checkthattherearenoobstaclesinthetravelarea, consideringtheoverall
dimensionsofthemachine;
–Themachineisco
mpletelyclosedandaligned,inthetransportorstabilisa‐
tionpositionorwiththeJIBarmpartiallyortotallyliftedinthetransport
orstabilisationposition.Thisconfigurationisonlyallowedwhenstrictly
necessary.
b Selectthetravelspeedaccordingtotheneedandasdescribedabove,opera‐
tingtherelevantbuttonandcheckingthesel
ectionondisplay;
c Operatejoysticks1and8tomovethetracks;
Iftheoperatorattemptstotravelwithoneormorestabilisersontheground, an
errormessagewillappearonthedispla ywarningtheusertoraisethestabilisers
inordertoallowthemachinetotravel.
Fig.87 Er
ror,raisetheoutriggersfromthegroundbeforetravelling
